Vaughan Sound’s live streaming solutions at St. Hilary’s Church, Killay have helped the parish to create a ‘Church Without Walls’

St. Hilary's Church - AV - Vaughan Sound

Client Overview

St. Hilary’s Church sits within the parish of Killay, around three miles west of Swansea city centre.

It forms part of the Gower Ministry Area – a community of 20 Anglican churches in the Diocese of Swansea and Brecon.

The parish includes the nearby All Souls Church in Tycoch and St. Martin’s Church in Dunvant.

The church was designed by local architect, Glendining Moxham and built in 1925-26.

Together, they serve the communities of Derlwyn, Dunvant, Hendrefoilan, Killay, Three Crosses, and Upper Killay.

Project Brief

Vaughan Sound was approached by the parish as they sought a new live streaming solution for St. Hilary’s Church that would be ‘very simply operated’.

The primary goal was to broadcast services on their new YouTube channel, to bolster a core aim of the parish in creating a ‘Church Without Walls’.

With capacity for just over 70 worshippers, St. Hilary’s required a system that would enable them to open up to a much wider audience, including the infirm and those unable to attend services in person.

Technical Solutions

The live streaming system needed to integrate with the existing audio-visual and sound equipment in situ, which was previously installed by Vaughan Sound and has been regularly serviced since.

Following a site meeting to ascertain the full brief and end user requirements, Vaughan Sound proposed a full high definition moving camera (PTZ), along with a fixed camera which would focus on a close up of the altar.

Direct feeds from the cameras and an audio connection from the worship venue’s sound system are connected into a Blackmagic Design ATEM Mini Pro. This has been configured to broadcast to the church’s YouTube channel without the need for an additional laptop or PC.

Furthermore, this setup provides the ability to access services on demand, as the streams are recorded by default onto the YouTube channel.

The existing sound equipment incorporated into the new setup includes wireless radio microphones and gooseneck condenser microphones installed at the pulpit and reader’s lectern.

The direct connection provides a high level of audio – a crucial element of any live stream.

With a 30x optical zoom, the broadcast camera specified by Vaughan Sound handles the various pre-set focal positions with ease, delivering crystal clear imagery.

The camera’s complete parameters can be configured and controlled easily via the included remote control, or alternatively the onboard web server. Additionally, pre-sets can be programmed and accessed effortlessly.

All live streaming cameras are cabled and connected using 3G-SDI, before converting to HDMI at the ATEM Mini Pro. Vaughan Sound’s selection of industry leading components ensures no latency issues.

Full training was provided as part of our project completion and handover. This involved conducting a test stream to ensure that everything worked as it should and that parish representatives were happy with all camera positions and feeds.

St Hilary’s Church successfully broadcasted its first live stream to its YouTube channel the following Sunday.

Intuitive control and simple operation are key features of the system – starting a new live stream before a service is ultimately straightforward and swift.

In addition to the live streaming equipment, a new ceiling mounted 4,000-lumen, WXGA, compact laser projector delivers powerful imagery in the church hall.

Combined with a digital stereo amplifier and a pair of wall-mounted passive loudspeakers for sound reinforcement, the facilities for church meetings and outside events have been greatly improved.

St Hilary’s Church is already benefitting hugely from the ease of use of the systems installed by Vaughan Sound.


The new audio-visual equipment has been extremely well received by worshippers.

St. Hilary’s Church aims to continue using the live streaming system each week to expand its network of channel followers, while supporting those who are unable to physically attend church.

Find out more about streamed services at St. Hilary’s here. You can also check out their growing YouTube channel and previous services here.


“[I just] wanted to say a big thank you for all the work.

“It’s all working a treat and is already being watched by some of our housebound.

“Thanks once again.”

– Alan Pickard, Treasurer (Parish of Killay)

Do you require audio-visual, sound or communications systems for your place of worship?

Click on the Contact Us button below to tell us what you need and we’ll get right back to you.

Project info

ClientParish of Killay
LocationKillay, Gower
EquipmentAV, Live Streaming, Microphones, Multimedia Projection, Sound System
